Toyota Supra
In February 1986, the bonds between the Celica and the Supra were cut; they were now two completely different models. The Celica changed to a front-wheel drive layout, using the Toyota "T" platform associated with the Corona, while the Supra kept its rear-wheel-drive layout. The engine was updated to a more powerful 2,954 cc (3.0 L) inline-six engine rated at 149 kW (200 hp; 203 PS). Although initially only available with naturally aspirated engines, a turbocharged version was added in the 1987 model year. The Supra was now mechanically related to the Soarer.
All Japanese market models with the various versions of the 2.0 L engine were slightly narrower overall so as to be in compliance with Japanese Government dimension regulations so that Japanese buyers weren't liable for yearly taxes for driving a larger car.
The new engine used in the A70 Supra, the Toyota 7M-GE, was the flagship engine of Toyota's arsenal. Both versions of the engine contained 4 valves per cylinder and dual overhead cams. The turbocharged 7M-GTE engine was Toyota's first distributor-less engine offered in the US which used coil packs sitting on the cam covers and a cam position sensor driven by the exhaust camshaft. It was equipped with a CT26 turbocharger and was rated at 172 kW (231 hp; 234 PS) at 5,600 rpm while the naturally aspirated 7M-GE engine was rated at 149 kW (200 hp; 203 PS) at 6,000 rpm. Further refinement on the turbo model increased power to 173 kW (232 hp; 235 PS) at 5,600 rpm and 254 lb⋅ft (344 N⋅m) of torque at 3,200 rpm in 1989. This was mostly due to a redesign of the wastegate. All models used the same tyre size of 225/50R16 on 16x7 inch wheels. Spare tyres were full-sized but on steel wheels.
The naturally aspirated model came standard with the W58 manual transmission. The turbocharged models included the R154 manual transmission. Both were available with the optional 4-speed A340E automatic transmission.
The third-generation of the Supra represented an arsenal of new technology. In 1986, options available for the Supra included a 3-channel ABS and TEMS which gave the driver two settings which affected the damper rates; a third was automatically activated at wide open throttle, hard braking and high speed maneuvering.
ACIS (Acoustic Control Induction System), a method of controlling air compression pulses inside the intake piping to increase power, was also a part of the 7M-GE's technological arsenal. All models were fitted with double wishbone suspension front and rear. A targa top was offered in all model years along with a metal power sliding sunroof (added in 1991).
Production numbers of the GA70/MA70/JZA70 Supra was estimated at 241,471 units.
The third generation of the Supra was introduced in February 1986 as a stand-alone model, officially being separate from the Celica. Whereas the Celica became a front-wheel-drive sport coupé, the Supra retained its image as a rear-wheel-drive sports/GT car. The new Supra would continue to move upscale and become a showcase for Toyota's technology. The Supra was powered by a 3.0-litre DOHC inline six-cylinder engine rated at 149 kW (200 hp; 203 PS). Notable features included an electronically controlled independent suspension (called the Toyota Electronic Modulated Suspension - TEMS), and some came with a removable Sport-Roof panel (Targa top).
The A70 Supra Turbo was introduced in 1987. The inter-cooled, turbocharged version of the 3.0-litre inline 6-cylinder engine boosted power to 172 kW (231 hp; 234 PS) and 240 lb⋅ft (325 N⋅m) of torque. The engine, designated as 7M-GTE, was one of the first distributor-less mass production engines in the United States. This was accomplished with 3 coils being shared using the wasted spark system. The Turbo model also included an engine oil cooler and an integrated rear spoiler. The sports package, which was standard on the Turbo and optional on the base model, included a limited slip differential (LSD), TEMS, and headlamp washers. A new 4-channel Anti-Lock Braking System (ABS) was optional on both models. In 1987, a new beige/tan colour combination was implemented, and only 1,000 cars were produced with this scheme. Toyota installed its variable induction technology into the DOHC twin-turbocharged 1G-GTE engine called T-VIS and also included it into the 7M-GTE engine as well.
Changes for the 1988 model year were nominal with the exception of the discontinuation of two-toned brown exterior paint. The spoiler mounted brake light changed from a square to a trapezoid shape. Seat pattern was changed from squares to lines, and "foil" on climate control and switch gear changed from light to dark gray. Japanese buyers could select from six different trim packages starting with the top level 3.0 GT Turbo Limited with the 7M-GTEU engine, followed by the 3.0 GT Turbo, GT Twin Turbo with the 1G-GTEU DOHC 2.0 L engine, the GT with the 2.0 L DOHC 1G-GEU engine, the G with the 1G-EU engine and the S with the 1G-EU engine as the base model. All Japanese models came with either a 5-speed manual transmission or the 4-speed automatic transmission with ECT-s except the G and the S on which the ECT-s wasn't available. In Japan, the 3.0 GT Turbo Limited, the 3.0 GT Turbo and the GT Twin Turbo were installed standard with a digital instrument panel, the 3.0 L models came with an AM/FM Cassette stereo with an integrated CD player and cruise control. Climate control was also standard on all turbocharged models, and leather interior was only available on the GT Turbo Limited.
Changes for the 1989 model year include modifications to the wastegate actuator, feed location and engine management increased power output by 1.5 kW (2 hp; 2 PS) on the turbo model. The engine mount and brace were also revised in late 1989. The changes made to the cross member and mounts made to accommodate the (1JZ engine) for Japanese models. The protective body molding was also changed by taking away the steel reinforcement. This made the molding lighter and prevented the rusting problem found on the previous year models. The "white package" was introduced as well, featuring white body molding and white "saw blade" wheels. Interior choices were limited to blue and burgundy only. Other than pure cosmetics changes, there was nothing different from other models. All models received rear 3-point seat belts to replace the previous years' two-point lap belts. New tail lights, front bumper with integrated lower grille (as opposed to the previous years' detachable grille), side mirrors, turn signals, upper grilles, foglights, steering wheel, door panels, climate control, window switches and bezels, and stereo. Addition of coat hooks on B-pillar and removal of rear seat pockets round out interior changes. Turbo models received three piece spoiler with an integrated LED brake light. 1989 also marked the end of headlight washers in the US and SuperMonitor; an advanced system offered by Toyota able to calculate miles able to be traveled on current tank, ability to check vehicle codes from inside the cabin, among other features.
For the 1990 model year, changes included larger protective laminate in front of rear wheels, lower redline (owing to the heavier crank with cylinders 2 & 5 counterbalanced), redesigned steering wheel with cruise control relocated to a stalk on the right side. In addition to an airbag and airbag indicator light on dashboard, the left side of the switch panel was also redesigned, which replaced one of the coin slots with the dimmer. The lower dashboard panel became a two piece design, which was also much heavier than the previous one piece panel owing to a change in material. Finally, the memory lever on the steering column was removed. In short, a plethora of the changes for the 1989 and 1990 were from the interior.
For the 1991 model year, the wheel design was changed to 5-spoke wheels. Both models had 16x7 aluminum alloy wheels that were fitted with 225/50/16 tyres and full-sized spares on steel wheels. Body molding changed in colour to better match the exterior. The front "Supra" emblem was also changed to the current corporate oval Toyota symbol was used from this model year onwards. The speedometer was also revised, and included more lines that were removed in 1989, but still did not have as many (one line per mph) as 1986.5 to 1988 models. New interior colours, namely shadow gray and deep red, were introduced, which marked the end of medium gray, tan and burgundy. Blue interior became only available on white packages, and those with blue paint. Burgundy was replaced with white package-only deep red. Every other body colour received a shadow gray interior, with leather interiors retaining medium gray seats and interior inserts. Front speakers were changed from 3.5 inch to 6.5 inches and the speaker cover was also enlarged to accommodate them. Beginning in 1991, Toyota began to offer a factory spoiler-style panel sunroof. These sunroofs are now highly sought after and rare since they were introduced in the ending production years of the A70 Supra.
For the 1992 model year, the leather shadow gray interiors received black seats and inserts. Non-turbo models lost the option of a targa top, and a new optional subwoofer was available. Subwoofer-equipped Supras did without the rear bins and wooden "floorboard". Instead, rear carpet was molded to the spare tire, and there was a cut-out for the woofer housing.
